I found the Atlas Signaling manuals. This link is to the index, the first and last with signals are the ones.  The first is the actual manual and the second is a wiring diagram for he signals. http://download.atlasrr.com/pdf/Instructions/

I looked at the design of the control module in the signal manual (HO and N) http://download.atlasrr.com/pdf/Instructions/Atlas%20Model%20Signal%20Manual.pdf
As far as I can tell, the Atlas design is a cascading independent with a separate detector board that signals input for the lights. It shows if someone is int eh next detected block.  If there is a unit ahead and it shows occupancy the signal is red. I do not see any reasonable way to use this to generate aspects.
